DOP-115WX - HMI 15“ TFT Touch Screen, Wide, Advanced

The specific model we offer here, the DOP-115WX, is an advanced HMI, meaning it has at least four COM ports. The DOP115-WX also has two Ethernet ports on board. It can be programmed with Delta's DOPSoft software, which can be downloaded for free from our website or from the Delta Electronics website. The 15-inch screen is a popular model; the screen is large enough for more advanced applications.

Component features:

• Display size: 15"
• Screen resolution: 1024*768
• Color display: 24-bit color TFT LCD
• Dual-core 1GHz MCU
• 1GB RAM / DDR3 1000MHz
• 8GB ROM
• Built-in RTC (Real-Time Clock)
• Built-in audio
• 4 sets of COM ports
• Built-in Ethernet: Yes (2 ports)
• USB host
• USB client
• Supports SD card
• CE/UL certified
• Operating temperature range: 0~50°C (32~122°F)
• Storage temperature: -20~60°C (-4~140°F)
• Operating cycles: >10,000
