M6x16 Bolt DIN-7984 08.8 Metric Low Head

Article number 6471
In Stock In Stock
General conditions
Quantity 200 - > 50,00 % on the retail price of €0,49 €0,25
EAN-number 8715492063045
€0,49 Excluding VAT Price per piece
Add to cart
Description
Attachments
Discount
Compatible Products

Hexagon socket head screw, with low head. Please note that the lower head allows for a smaller wrench width of 4mm instead of 5mm that can be used, which means that the torque that can be transferred is more limited than with the standard DIN912 bolts.

Component features:

  • Thread type: Metric M6
  • Length under the head: 16mm
  • AlleKey width: 4mm
  • Material: Steel, class 08.8, galvanized
  • Head Height: 4mm
  • Head Diameter: 10mm
  • DIN 7984
  • ISO 7045

Attachments

Here you can find all attachments that are linked to the product. Click on the icon to download.

6471-1_M6x16_Bolt_DIN-7984_08.8_Metric_Low_Head_STEP214.stp 6471-1 M6x16 Bolt DIN-7984 08.8 Metric Low Head STEP214
6471-2_M6x16_Bolt_DIN-7984_08.8_Metric_Low_Head_STEP242.stp 6471-2 M6x16 Bolt DIN-7984 08.8 Metric Low Head STEP242
6471-3_M6x16_Bolt_DIN-7984_08.8_Metric_Low_Head__2D_Dimensions.pdf 6471-3 M6x16 Bolt DIN-7984 08.8 Metric Low Head 2D Dimensions
