AC Servo Motor 750W ECMA-C20807RS

Article number 1157
Delta
In Stock In Stock
General conditions
Quantity 3 - > 5,00 % on the retail price of €350,00 €332,50
Quantity 5 - > 10,00 % on the retail price of €350,00 €315,00
Quantity 10 - > 15,00 % on the retail price of €350,00 €297,50
€350,00 Vat. excluded Price per piece
With or Without Brake
Without Brake
Servo Power
750W
Frame Size
80x80mm
Shaft Diameter
19mm h6
Rated Speed
3000RPM(nN)
Maximum Speed
5000RPM(max)
Rated Torque
2.39 Nm
Rotor Inertia
1.13 x 10-4kg-m2
Description
Attachments
Discount
Replaced by product

We no longer sell this product. It has been replaced by its successor, the Delta ECM-B3M servo motors, which offer increased performance. Despite this increased performance, the new ECM-B3M servo motors are much more compact. The flange sizes and shaft diameters have remained the same, which makes switching from ECMA motors to ECM-B3M motors possible without any problems. Please check the "Replaced by product" tab for its successors.

NOTE: We sometimes do have stock, which is then also visible in our webshop. This stock is very rare. And if you buy more than we have in stock, we can not guarantee that we can deliver it. The stock is intended for clients who have old machines, and need the older ECMA style servomotors to keep them running. The pricing is also higher then a newer Delta B3M servomotor. It is possible to run the old ECMA servo motors on the newer B3(A) and A3(A) servo drivers. The newer B3(A) drivers will work also with the older ECMA style servo motors. The opposite is not possible, so a new B3M servo motor will not run on an old A2 or B2 driver.  For the long terms it's best to convert your machines to the Delta B3 and A3 system. If you have any questions, feel free to contact us by email.

Component features:

  • WARNING: This product is no longer in production, do not use in new machines!!!
  • Frame size: 80 x 80 mm
  • Shaft diameter: 19 mm
  • Rated output power: 750 W
  • Speed range: 0 - 3000 rpm
  • 17-bit Rotary Optical Encoder

Attachments

Here you can find all attachments that are linked to the product. Click on the icon to download.

1157_ECMA-C20807RS_STEP214.stp 1157 ECMA-C20807RS STEP214
DELTA_ASDA-B2_Catalogue_English_2019.pdf DELTA ASDA-B2 Catalogue English 2019
DELTA_ASDA-B2_User_Manual_English_2018.pdf DELTA ASDA-B2 User Manual English 2018
