BF10_C3 Floating Ballscrew Support Units (C3 Quality)

Article number 3899
In Stock In Stock
General conditions
Amount 3 - > 5,00 % on the retail price of 21,99 20,89
Amount 5 - > 10,00 % on the retail price of 21,99 19,79
Amount 10 - > 15,00 % on the retail price of 21,99 18,69
Amount 20 - > 20,00 % on the retail price of 21,99 17,59
21,99 Excluding VAT Price per piece
Description
Attachments
Discount
Compatible Products

The BF Floating Ballscrew Support Units, or used in combination with the BK Fixed Ballscrew Support Units. For example for a BK10 the counterpart is the BF10. The only thing that is a bit confusing, is that a BK10 has a 10mm inside diameter like you would expect, but the BF10 that goes on the floating end has an 8mm bore. Once you know, and have the correct end machining on the ballscrew it's no problem at all.


Component features:

  • Type of support used on the floating side (can only take radial loads)
  • Compatible with BK series Fixed bearing blocks
  • Exchangeable with other brands like THK, NSK, MISUMI, KURODA
  • In this design the bearing is fixed to the ballscrew, and the bearing can move freely in axial direction through the floating housing

Attachments

Here you can find all attachments that are linked to the product. Click on the icon to download.

3899_BF10_STEP214.stp 3899 BF10 STEP214
