M12 4-pole Angle Male Connector (1424654)

Article number 4798
PHOENIX CONTACT
In Stock In Stock
General conditions
Numbers 5 - > 5,00 % on the retail price of € 9,99 € 9,49
Numbers 10 - > 10,00 % on the retail price of € 9,99 € 8,99
Numbers 50 - > 20,00 % on the retail price of € 9,99 € 7,99
EAN-number 4055626375816
9,99 Excluded VAT Price per piece
Description
Attachments
Discount

These connectors are compatible with our plug and play sensor system that is used in the RTR sets. This connector is intended for those who which to connect other sensors than we supply, or to make custom cable lengths. The connectors are high quality push in type connectors, which makes the connection quite easy. The pins are colour coded which make it even easier to connect.

Component features:

  • Plug and Play with our Pluggable Inductive Sensor and RTR sets
  • Degree of protection: IP65 (Cable mounted)
  • Input wire 4mm to 8mm diameter
  • Number of poles: 4
  • Gender: MALE
  • 90 degree angle type
  • Cable can exit relative to poles at 0,45,90,135 etc degrees
  • Type of Termination: PUSH-IN
  • Polarisation: A (standard)
  • Manufacturer part nr: Phoenix Contact 1424654 SACC-M12MR-4PL M

Attachments

Here you can find all attachments that are linked to the product. Click on the icon to download.

4798-1_M12_4-pole_Angle_Male_Connector_(1424654)_STEP214.stp 4798-1 M12 4-pole Angle Male Connector (1424654) STEP214
4798-2_M12_4-pole_Angle_Male_Connector_(1424654)_Datasheet.pdf 4798-2 M12 4-pole Angle Male Connector (1424654) Datasheet
